Technoscope F32
The Technoscope F32 is specifically designed to capture highly complex, graceful, and extended sweeping shots with ease and precision. Its portability and versatile design allow for effortless handling and transportation to different locations, quick setup, highly effective and user-friendly control, providing an impressive operational experience. The F32 is an invaluable tool that enhances storytelling and offers filmmakers a wide range of creative possibilities. Thanks to its lightweight design, maneuvering the crane is exceptionally comfortable, effortless, and efficient.
SPECS
Max Payload (Head + Camera)
27 kg (60 lbs)
Max Length (Pivot to Front End)
10.2 m (33.46 ft)
Min Length (Pivot to Front End)
1.87 m (6.14 ft)
Rear Section Length (Pivot to Rear End)
1.7 (5.58 ft)
Max Lens Height Underslung
9.1 m (29.86 ft)
Telescopic Travel
8.3 m (27.23 ft)
Telescopic Travel Speed
2.5 m/s (8.2 ft/s)
Dolly Length
1.2 m (3.94 ft)
Dolly Width
1.03 m (3.38 ft)
Total Maximum Weight
770 kg (1698 lbs)
Footprint 360° Length
5 m (16.4 ft)
Footprint 360° Width
5 m (16.4 ft)
Footprint 180° Length
5 m (16.4 ft)
Footprint 180° Width
4 m (13.12 ft)
Min Door Width
1.03 m (3.38 ft)
Min Door Height
1.86 m (6.10 ft)
Power Requirement
220 V, 16 Amp
Weather Proof
Ja
Raincover
Ja
Track Wheels
Ja
Track Size
620 mm (2.03 ft)
