GF-Jib
The GF-Jib Arm was designed to operate as a stable, fixed jib specifically for the heavier 35mm camera packages. It offers smooth, vibration-free movement. The front of the arm can easily be extended and locked at the desired working length. The jib's pan and tilt "drag" can be adjusted to individual preferences.
The jib can be mounted on a tripod at various dollies (Panther, Fisher ...). This by using a Euro-adapter / Mitchell.
SPECS
Max Payload (Head + Camera)
60 kg (132 lbs)
Max Length (Pivot to Front End)
1.88 m (6.17 ft)
Min Length (Pivot to Front End)
1.33 m (4.36 ft)
Rear Section Length (Pivot to Rear End)
0.48 m (1.57 ft)
Max Lens Height Overslung
2.56 m (8.4 ft)
Max Lens Height Underslung
2.56 m (8.4 ft)
Total Maximum Weight
220 kg (485 lbs)
