Black-Tek Tower 24
The Black-Tek Tower 24 is a vertical lifter for remoteheads and can be mounted on camera cars and or even used stationary. The Black-Tek Tower 24 can be used with smaller remoteheads like the Flighthead Mini 4 or Shotover G1 and is controlled by the camera operator via joystick or a foot pedal. The Black-Tek Tower 24 includes a shockabsorber to reduce unwanted vertical movement. With this shockabsorber, the total weigt of The Black-Tek Tower 24 comes to 34kg (75lbs).
The Black-Tek Tower 24 can be provided with power-packs to use as an powersource for the tower, as well as the remotehead or any other device that needs to be powered.
- Manually rotatable position in 45° steps
- Chain inside the Tower for command, power and video cable
- Internal weight balancing system to reduce power consumption
- Mitchellplate as base on the shock-absorber
- Hand control for selecting speed and position
- Can be mounted on 33mm CarRig pipes
- Powered from 24V up to 48 V
- Can also be used as a motorized horizontal slider
SPECS
Max Payload (Head + Camera)
30kg (66lbs)
Max height
240cm
Vertical Travel
210cm
Lift speed
1 m/s
Total weight
34 kg (75lbs)
Joystick Control
Yes
Pedal Control
Yes
